AIMILER 48A Hardwired Level 2 EV Charger

The AIMILER Level 2 Hardwired EV Charger (Model ZB18-U011KBH-F002) is a high-capacity residential charging station built for electric vehicle owners looking to move past slow domestic trickle leads.

Operating as a dedicated 240V hardware setup, this wall-mounted unit can supply up to 48 Amps of continuous current when tied to an appropriate electrical breaker line.

This output yields rapid charging speeds that deliver up to 11.5 kW of power, making it an excellent investment for commuters with large vehicle battery capacities who require quick, dependable overnight replenishment.

Specifications

• ASIN: B0FZJQ3JYK

• Input / output voltage: 240V AC

• Amperage: Adjustable from 24A to 48A continuous (Requires $\ge$ 60A circuit breaker for maximum 48A output)

• Power rating: Up to 11.5 kW

• Product dimensions: 17 x 14 x 8 inches

• Item weight: 19.26 lbs (approx. 8.7 kg)

• Connector type: SAE J1772 standard

• Cable length: 25 ft (8 AWG wiring)

• Connectivity: 2.4GHz Wi-Fi and Bluetooth

• Display: Onboard smart touch screen with physical adjustment buttons

• Waterproof rating: NEMA Type 4 (IP66 equivalent)

• Certifications: ETL, FCC, UL2231-1/-2, UL 991, UL 2251, UL 1998, and UL 2594 listed

• Warranty: 3-year warranty

Performance

The AIMILER Level 2 Hardwired EV Charger delivers excellent charging performance for households that need fast, reliable power on a daily basis.

With a maximum output of 48 amps and up to 11.5 kW on a 240V circuit, it can add substantial driving range each hour, making it ideal for larger battery electric vehicles and drivers with demanding commuting schedules.

Its adjustable current settings (24A, 32A, 40A, and 48A) allow the charger to match different electrical system capacities while maintaining stable power delivery.

Today's best deals

• AIMILER Level 2 Hardwired EV Charger (48A) — Amazon — View at Amazon

Reasons to buy

• Blazing high-speed home charging: Delivers up to 11.5 kW of high-speed power to charge vehicles roughly nine times faster than basic Level 1 travel alternatives.

• Highly flexible adjustable amperage: Built-in current regulation lets you easily select between 24A, 32A, 40A, or 48A outputs to accommodate various circuit capabilities safely.

• Data-rich physical screen interface: The integrated touch screen allows users to configure delay timers and track charging parameters without needing a phone.

• Intelligent app automation features: Syncs seamlessly with the Smart Life app over Wi-Fi to establish cost-saving charging schedules and monitor continuous data remotely.

• Superior structural weather protection: Carries an industrial NEMA Type 4 waterproof rating, ensuring the internal electronics remain completely dry through intense rainfall.

Reasons to avoid

• Demands professional installation infrastructure: Lacks a standard domestic plug attachment, requiring a certified electrician to secure it to a dedicated 60A breaker line.

• No 5GHz Wi-Fi network support: The smart application integration communicates strictly over 2.4GHz bands, which may create pairing challenges on modernized dual-band home routers.

• Tesla cars require an accessory: Features a North American SAE J1772 connector head, meaning Tesla owners must rely on an additional NACS adapter to hook up successfully.
